ExxonMobil has compiled five "top tips" to help vessel operators effectively switch fuels when entering and exiting Emission Control Areas (ECAs) without introducing maintenance issues.
In a statement released today, ExxonMobil explained that the inadequate management of the fuel switchover process can increase the risk of thermal shock to engine components, which in turn can result in fuel pump seizures and engine shutdowns.
The oil major therefore advises marine operators to consider the following five "key" fuel switching tips:
Have a clear switchover procedure
"It is important to ensure that the crew is familiar with the process. As an additional safety measure, the procedure should be tested prior to entering crowded and restricted channels where there is a higher risk of grounding or collision," Exxon Mobil said.
Outline the best time to switchover
"The optimal switchover period is different for each vessel and operators must allow sufficient time for the fuel system to be flushed of all non-compliant fuel before arriving at an ECA limit," Exxon Mobil explained.
Avoid hazards; know the correct temperature and viscosity
"The viscosity of heavy fuel oil (HFO), ECA fuels and marine gas oil (MGO) are very different. The appropriate temperature must be achieved to ensure that the optimum viscosity at the injectors is reached. HFO is injected at ~130°C and MGO needs to be cooled to ~30°C in order to reach the correct viscosity. Major engine manufacturers typically recommend a maximum temperature change of 2°C per minute to help avoid thermal shock," commented Exxon Mobil.
Understand compatibility
"There is a potential risk of fuel incompatibility during the switching process where fuels may mix. This may clog filters, causing engine starvation and possible shut down. In order to understand if fuels are compatible, an industry-standard spot test can be carried on-board or a more thorough compatibility test can be requested from a reputable testing laboratory," Exxon Mobil said.
Choose the correct lubricant
"Cylinder oils need to be sufficiently alkaline to neutralise any corrosive acidic sulphur in the fuel. However, when less sulphur is present, less sulphuric acid is produced. Too much alkalinity in the cylinder oil can lead to liner wear, while too little increases the risk of acid corrosion. When burning low-sulphur fuels in slow-speed engines, it is recommended that a lower base number lubricant be used," Exxon Mobil stated.
In addition to these top-tips, ExxonMobil has developed two ECA category fuels:
ExxonMobil Premium AFME 200 and
ExxonMobil Premium HDME 50, that are designed to help operators comply with ECA requirements safely.
